Detail produk:
Syarat-syarat pembayaran & pengiriman:
|
| Kekuatan Operasi: | Tipe standar: AC230V 50/60HZ | Tipe khusus: | AC110V 24V |
|---|---|---|---|
| Metode Koneksi: | Flens | Mode penggerak: | P、 PI、 PID.digerakkan oleh motor servo Juga dapat dioperasikan oleh 0/4-20mA0/2-10VDC |
| Bahan: | SUS316, ,304 | Aksesoris: | pencari lokasi, sakelar batas katup solenoid |
| Media yang berlaku: | Media yang berlaku semua jenis media yang tidak mengandung partikel jelas | Kisaran Suhu: | -30~-350~C |
| Tekanan (MPa): | PN16 | Jenis penyegelan: | tipe segel bellow plus kelenjar pengaman plus penyegelan PTFE yang mengandung grafit |
| Torsi aktuator: | 2000N、4000N、9000N、10000N | Bahan cincin/cakram dudukan katup: | 1.SUS316L paduan keras 2.PTFE mengandung grafit |
The body uses iron coated sand casting process compared with the traditional technology, there is no swelling phenomenon, body wall thickness, no pores, trachoma material of high density, more exquisite appearance The valve body and stainless steel valve port in the casting process once molding, the valve port will not have deformation phenomenon, long time high temperature use will not exist outside the valve leakage phenomenon, to ensure that the valve port factory pressure test 0 leakage. This foundry technology has obtained national patent in our company. The sealing ring is made of PTFE+ carbon fiber material, which has better wear resistance The paint paint line and drying equipment make the paint adhesion stronger, the anti-corrosion effect is better, the valve body gloss has been significantly improved.
Product Overviews
| Body type: | straight through casting globe type |
|---|---|
| Spool type: | multi-layer choke spool |
| Nominal size: | DN20~200 NPS 3/4 inch~ 8 inch |
| Nominal pressure: | PN160 ~ 420 CLASS 900LB ~2500LB |
| Connection: flange: | flange: FF,RF,MF,RTJ |
| Welding: SW,BW | |
| Bonnet type: | standard type(-5℃~230℃), Radiator type: (-45℃~higher than 230℃ occasion), Low temperature extended type(-196℃~ -45℃) |
| Packing: | V type PFTE packing, flex. graphite packing, etc. |
| Gasket: | Metal graphite packing |
| Actuator: | pneumatic: multi-spring diaphragm actuator, piston type actuator. electric: 3810L series smart actuator, PSL series actuator. |
| Surface painting: |
Green color, acrylic acid polyurthene ceramic paint. |
Q1. How to place the order?
A1: You can send us email or inquiry at alibaba directly.
Q2: Can you provide the free samples?
A2:Yes, the free samples is available. You just need to pay the freight cost.
Q3: Can I have my own customized product?
A3: Yes, your customized requirements for color, size, package, mark, etc.
Q4. Do you test all your goods before delivery?
A4: Yes, we have 100% test before delivery.
Q5: How long is your delivery time?
A5: Generally it is 10-20 days if the goods are in stock. Customized goods need to negotiate delivery.
